20-30 HP 2WD Loader Backhoe

NEED ASSISTANCE? CALL NOW (888) 325-5172
wa50-66

Pricing and Availability

(888) 325-5172Reserve your equipment today!

Request A Quote








Details

Selected Dimensions

Backhoe
Load Height – Std 7.8 ft in 2381 mm
Reach From Swivel – Std 11.9 ft in 3630 mm
Dig Depth – Std 9.2 ft in 2817 mm
Dimensions
Transport Length 17.8 ft in 5436 mm
Transport Width 5.2 ft in 1600 mm
Wheelbase 5.4 ft in 1638 mm
Height to Top of Cab 7.6 ft in 2311 mm
Loader
Clearance at Max Dump Height 5.7 ft in 1750 mm
Reach at Max Dump Height 3.9 ft in 1203 mm
Dig Depth 2.6 in 66 mm

Specification

Engine
Make Kubota
Model D1105
Net Power 31.5 hp 23.5 kw
Aspiration turbocharged
Operational
Operating Weight 2wd 5752 lb 2609.1 kg
Fuel Capacity 14.5 gal 54.9 L
Turning Radius 14.1 ft in 4297.7 mm
Tire Size Front – 2wd / 4wd 23×8.5×12
Rear Tires Size 2wd/4wd 31×15.5×15
Transmission
Type hydrostatic
Max Speed – Forward 4.7 mph 7.6 km/h
Backhoe
Dig Depth – Std 9.2 ft in 2817 mm
Reach From Swivel – Std 11.9 ft in 3630 mm
Bucket Dig Force – Std 5409 lb 2453.5 kg
Load Height – Std 7.8 ft in 2381 mm
Loader
Bucket Capacity 0.48 yd3 0.37 m3
Bucket Breakout Force 3600 lb 16 kN
Lift Capacity at Full Height 2250 lb 1020.6 kg
Clearance at Max Dump Height 5.7 ft in 1750 mm
Reach at Max Dump Height 3.9 ft in 1203 mm
Dig Depth 2.6 in 66 mm
Dimensions
Transport Length 17.8 ft in 5436 mm
Transport Width 5.2 ft in 1600 mm
Height to Top of Cab 7.6 ft in 2311 mm
Wheelbase 5.4 ft in 1638 mm

You will receive a rental product of similar specifications to the above models, based on availability in your area. A specific make and model cannot be guaranteed.


Representative image – models may vary.

Horsepower: 20hp - 30hp
Fuel Type: Diesel
Options: 2WD
Typical Models: Honda 20-hp Gas - Honda 24hp gas - Kohler 25hp Diesel
