40,000 – 45,000 lb Crawler Excavator

NEED ASSISTANCE? CALL NOW (855) 253-1369
pc88mr-83

Pricing and Availability

(855) 253-1369Reserve your equipment today!

Request A Quote








Details

Selected Dimensions

Shipping Length of Unit 31.2 ft in 9500 mm
Shipping Height of Unit 9.7 ft in 2970 mm
Max Cutting Height  ft in  mm
Max Loading Height 22.2 ft in 6780 mm
Max Reach Along Ground 32 ft in 9750 mm
Max Vertical Wall Digging Depth 19.8 ft in 6050 mm
Max Digging Depth 21.9 ft in 6680 mm
Shipping Length of Unit  ft in  mm
Shipping Height of Unit  ft in  mm
Max Cutting Height  ft in  mm
Max Loading Height  ft in  mm
Max Reach Along Ground  ft in  mm
Max Vertical Wall Digging Depth  ft in  mm
Max Digging Depth  ft in  mm
Dimensions
Width to Outside of Tracks 10.5 ft in 3200 mm
Length of Track on Ground 12 ft in 3660 mm
Ground Clearance 1.5 ft in 450 mm
Height to Top of Cab  ft in  mm
Tail Swing Radius 9 ft in 2740 mm
Counterweight Clearance  ft in  mm
Undercarriage
Track Gauge 7.8 ft in 2390 mm
Shoe Size 31.9 in 810 mm

Specification

Engine
Make John Deere
Model 6068H
Net Power 141 hp 105.1 kw
Power Measured @ 2150 rpm
Displacement 414 cu in 6.8 L
Torque Measured @ 1300 rpm
Max Torque 427 lb ft 579 Nm
Aspiration Turbocharged
Number of Cylinders 6
Operational
Operating Weight 46130 lb 20924.2 kg
Fuel Capacity 95.1 gal 360 L
Cooling System Fluid Capacity  gal  L
Hydrauilc System Fluid Capacity 34 gal 128.7 L
Engine Oil Capacity  gal  L
Swing Drive Fluid Capacity  gal  L
Operating Voltage  V
Alternator Supplied Amperage  amps
Hydraulic System Relief Valve Pressure 4980 psi 34335.9 kPa
Hydraulic Pump Flow Capacity 115.7 gal/min 438 L/min
Swing Mechanism
Swing Speed 13.3 rpm
Swing Torque  lb ft  Nm
Undercarriage
Number of Shoes per Side
Shoe Size 31.9 in 810 mm
Number of Carrier Rollers per Side 2
Number of Track Rollers per Side 8
Ground Pressure 4.7 psi 32.5 kPa
Max Travel Speed 3.4 mph 5.5 km/h
Drawbar Pull 42420 lb 188.7 kN
Track Gauge 7.8 ft in 2390 mm
Buckets
Reference Bucket Capacity 1.1 yd3 0.86 m3
Minimum Bucket Capacity 0.77 yd3 0.59 m3
Maximum Bucket Capacity 2.1 yd3 1.6 m3
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1 9’7″ (2910mm) stick
Shipping Height of Unit 9.7 ft in 2970 mm
Shipping Length of Unit 31.2 ft in 9500 mm
Max Digging Depth 21.9 ft in 6680 mm
Max Reach Along Ground 32 ft in 9750 mm
Max Cutting Height  ft in  mm
Max Loading Height 22.2 ft in 6780 mm
Max Vertical Wall Digging Depth 19.8 ft in 6050 mm
Boom/Stick Option (HEX) 2
Boom/Stick Option (HEX) 2
Shipping Height of Unit  ft in  mm
Shipping Length of Unit  ft in  mm
Max Digging Depth  ft in  mm
Max Reach Along Ground  ft in  mm
Max Cutting Height  ft in  mm
Max Loading Height  ft in  mm
Max Vertical Wall Digging Depth  ft in  mm
Dimensions
Width to Outside of Tracks 10.5 ft in 3200 mm
Height to Top of Cab  ft in  mm
Ground Clearance 1.5 ft in 450 mm
Counterweight Clearance  ft in  mm
Tail Swing Radius 9 ft in 2740 mm
Length of Track on Ground 12 ft in 3660 mm

You will receive a rental product of similar specifications to the above models, based on availability in your area. A specific make and model cannot be guaranteed.


Representative image – models may vary.

Fuel Type: Diesel
Options: 45000 lbs / 21' Dig Depth
Typical Models: Case CX210B - John Deere 200C LC - Kobelco SK210LC
