16,000 lb Mini Excavator

NEED ASSISTANCE? CALL NOW (855) 253-1369
r4b012234_60g_642x462

Pricing and Availability

(855) 253-1369Reserve your equipment today!

Request A Quote








Details

Selected Dimensions

Boom/Stick Option (HEX) 1
Shipping Length of Unit 13.9 ft in 4242.8 mm
Shipping Height of Unit 8.4 ft in 2550 mm
Max Cutting Height 13.9 ft in 4242.8 mm
Max Loading Height 9.8 ft in 2996.2 mm
Max Reach Along Ground 15.4 ft in 4700 mm
Max Vertical Wall Digging Depth 6.7 ft in 2033 mm
Max Digging Depth 8.7 ft in 2642.6 mm
Dimensions
Width to Outside of Tracks 5.1 ft in 1548.4 mm
Length of Track on Ground 6.3 ft in 1929.4 mm
Ground Clearance 1.2 ft in 356.6 mm
Height to Top of Cab 8.4 ft in 2550 mm
Tail Swing Radius 2.6 ft in 786.4 mm
Counterweight Clearance 1.8 ft in 533.4 mm
Undercarriage
Shoe Size 11.8 in 300 mm

Specification

Engine
Make Isuzu
Model 3LD2
Gross Power 32 hp 23.9 kw
Power Measured @ 2450 rpm
Displacement 91.5 cu in 1.5 L
Operational
Operating Weight 6482 lb 2940.2 kg
Fuel Capacity 10.5 gal 39.7 L
Hydrauilc System Fluid Capacity 7.9 gal 29.9 L
Operating Voltage 12 V
Alternator Supplied Amperage 35 amps
Hydraulic Pump Flow Capacity 12.6 gal/min 47.7 L/min
Swing Mechanism
Swing Speed 8.9 rpm
Undercarriage
Shoe Size 11.8 in 300 mm
Ground Pressure 3.8 psi 26.2 kPa
Max Travel Speed 2.5 mph 4 km/h
Buckets
Reference Bucket Capacity 0.08 yd3 0.06 m3
Minimum Bucket Capacity 0.05 yd3 0.04 m3
Maximum Bucket Capacity 0.16 yd3 0.12 m3
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1 Arm Length 3ft. 10in. (1170mm )
Shipping Height of Unit 8.4 ft in 2550 mm
Shipping Length of Unit 13.9 ft in 4242.8 mm
Max Digging Depth 8.7 ft in 2642.6 mm
Max Reach Along Ground 15.4 ft in 4700 mm
Max Cutting Height 13.9 ft in 4242.8 mm
Max Loading Height 9.8 ft in 2996.2 mm
Max Vertical Wall Digging Depth 6.7 ft in 2033 mm
Dimensions
Width to Outside of Tracks 5.1 ft in 1548.4 mm
Height to Top of Cab 8.4 ft in 2550 mm
Ground Clearance 1.2 ft in 356.6 mm
Counterweight Clearance 1.8 ft in 533.4 mm
Tail Swing Radius 2.6 ft in 786.4 mm
Length of Track on Ground 6.3 ft in 1929.4 mm

You will receive a rental product of similar specifications to the above models, based on availability in your area. A specific make and model cannot be guaranteed.


Representative image – models may vary.

Fuel Type: Diesel
Options: 16000 lbs
Typical Models: Bobcat 325 - 328 - JCB 8025 - 8027 - John Deere 27C - 27D
