25,000 – 29,000 lb Crawler Excavator

NEED ASSISTANCE? CALL NOW (855) 253-1369
r4a037882_rrd_75g_642x462

Pricing and Availability

(855) 253-1369Reserve your equipment today!

Request A Quote








Details

Selected Dimensions

Shipping Length of Unit 24.9 ft in 7580 mm
Shipping Height of Unit 8.8 ft in 2680 mm
Max Cutting Height 27.7 ft in 8433.8 mm
Max Loading Height 20.6 ft in 6272.8 mm
Max Reach Along Ground 26.3 ft in 8025.4 mm
Max Vertical Wall Digging Depth 16 ft in 4876.8 mm
Max Digging Depth 17.8 ft in 5434.6 mm
Shipping Length of Unit 24.9 ft in 7590 mm
Shipping Height of Unit 8.8 ft in 2670 mm
Max Cutting Height 28.8 ft in 8763 mm
Max Loading Height 21.7 ft in 6605 mm
Max Reach Along Ground 27.1 ft in 8254 mm
Max Vertical Wall Digging Depth 17.6 ft in 5358.4 mm
Max Digging Depth 19.5 ft in 5943.6 mm
Dimensions
Width to Outside of Tracks 8.5 ft in 2590 mm
Length of Track on Ground 9.4 ft in 2880 mm
Ground Clearance 1.3 ft in 400 mm
Height to Top of Cab 8.9 ft in 2720 mm
Tail Swing Radius 6.9 ft in 2100 mm
Counterweight Clearance 2.9 ft in 890 mm
Undercarriage
Track Gauge 6.5 ft in 1990 mm
Shoe Size 23.6 in 600 mm

Specification

Engine
Make John Deere
Model 4045T
Net Power 90 hp 67.1 kw
Power Measured @ 2200 rpm
Displacement 276 cu in 4.5 L
Torque Measured @ 1400 rpm
Max Torque 260 lb ft 352.5 Nm
Aspiration Turbocharged
Number of Cylinders 4
Operational
Operating Weight 26790 lb 12151.7 kg
Fuel Capacity 66 gal 249.8 L
Cooling System Fluid Capacity 5.8 gal 22 L
Hydrauilc System Fluid Capacity 35 gal 132.5 L
Engine Oil Capacity 3.4 gal 13 L
Swing Drive Fluid Capacity 0.74 gal 2.8 L
Operating Voltage 24 V
Alternator Supplied Amperage 45 amps
Hydraulic System Relief Valve Pressure 4980 psi 34335.9 kPa
Hydraulic Pump Flow Capacity 26.7 gal/min 101.1 L/min
Swing Mechanism
Swing Speed 12.7 rpm
Swing Torque 22415 lb ft 30390.7 Nm
Undercarriage
Number of Shoes per Side 44
Shoe Size 23.6 in 600 mm
Number of Carrier Rollers per Side 1
Number of Track Rollers per Side 7
Ground Pressure 4.6 psi 31.4 kPa
Max Travel Speed 3.4 mph 5.5 km/h
Drawbar Pull 22050 lb 98.1 kN
Track Gauge 6.5 ft in 1990 mm
Buckets
Reference Bucket Capacity 1 yd3 0.79 m3
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1 Arm Length 8ft.3in. ( 2.52m
Shipping Height of Unit 8.8 ft in 2680 mm
Shipping Length of Unit 24.9 ft in 7580 mm
Max Digging Depth 17.8 ft in 5434.6 mm
Max Reach Along Ground 26.3 ft in 8025.4 mm
Max Cutting Height 27.7 ft in 8433.8 mm
Max Loading Height 20.6 ft in 6272.8 mm
Max Vertical Wall Digging Depth 16 ft in 4876.8 mm
Boom/Stick Option (HEX) 2
Boom/Stick Option (HEX) 2 Arm Length 9ft. 11in. (3.01m )
Shipping Height of Unit 8.8 ft in 2670 mm
Shipping Length of Unit 24.9 ft in 7590 mm
Max Digging Depth 19.5 ft in 5943.6 mm
Max Reach Along Ground 27.1 ft in 8254 mm
Max Cutting Height 28.8 ft in 8763 mm
Max Loading Height 21.7 ft in 6605 mm
Max Vertical Wall Digging Depth 17.6 ft in 5358.4 mm
Dimensions
Width to Outside of Tracks 8.5 ft in 2590 mm
Height to Top of Cab 8.9 ft in 2720 mm
Ground Clearance 1.3 ft in 400 mm
Counterweight Clearance 2.9 ft in 890 mm
Tail Swing Radius 6.9 ft in 2100 mm
Length of Track on Ground 9.4 ft in 2880 mm

You will receive a rental product of similar specifications to the above models, based on availability in your area. A specific make and model cannot be guaranteed.


Representative image – models may vary.

Fuel Type: Diesel
Options: 25000 lbs
Typical Models: JCB JS130 - John Deere 120 - New Holland E130
